Mikrotik RB2011UAS-2HnD-IN, 128MB RAM, RouterOS L5 | RB2011UiAS-2HnD-IN

RouterBOARD 2011UAS-2HnD has most features and interfaces from all our Wireless routers. It’s powered by the new Atheros 600MHz 74K MIPS network processor, has 128MB RAM, five Gigabit LAN ports, five Fast Ethernet LAN ports and SFP cage (SFP module not included!). Also, it features powerful (up to 1W!) dual chain 2.4Ghz 802.11bgn wireless, RJ45 serial port, microUSB port and RouterOS L5 license, as well as desktop case with power supply, two 4dBi Omni antennas and LCD panel.


Product specifications
· Product code: RB2011UAS-2HnD-IN
· Antenna gain: 4dbi
· TX power: 30dBm
· Current Monitor: No
· CPU: Atheros AR9344
· Max Power consumption: 11W
· SFP ports: 1
· CPU speed: 600MHz
· RAM: 128MB
· 10/ 100 Mbit LAN ports: 5
· Gigabit LAN ports: 5
· Integrated Wireless: yes
· Wireless standards: 802.11b/ g/ n
· USB: microUSB
· Power Jack: 8-28V DC
· 802.3af support: No
· PoE: 8-28V DC on Ether1
· Voltage Monitor: Yes
· PCB temperature monitor: Yes
· CPU temperature monitor: No
· Dimensions: 214mm x 86mm for PCB
· Operating System: RouterOS (license L5)

Powering
The device accepts powering from either the power jack, or from the LAN1 Ethernet port:
· Direct input power jack (5.5mm outside and 2mm inside diameter, female, pin positive plug) accepts 8-30V DC (overvoltage protection starts at 30V)
· Eth1 port accepts 8-30V DC input (at the board; higher voltage needed to compensate for power loss on long cables) from non-standard (passive) Power over Ethernet injectors. The board does not work with IEEE802.3af compliant 48V power injectors
· The IN and RM models include a 110/ 220VPSU which is already plugged into the power jack inside the case

Extension Slots and Ports
· Five 10/ 100/ 1000 (Gigabit) Ethernet ports (Auto MDI/ X)
· Five 10/ 100 (Fast) Ethernet ports (Auto MDI/ X)
· One8-30V DC power jack
· SFP port for SFP module (module not included)
· (on RB2011US-2HnD-IN) built in 2GHz wireless device with external antennas, 802.11


Dokumenty:

• Odkaz na web výrobce [url]
• Datasheet [pdf]
