Cisco RV132W Wireless-N VPN Router | RV132W-E-K9-G5

Tento model je určen pro provoz v ANNEXu A, v ČR a SK je převážně využíván ANNEX B - Prosím zkontrolujte před koupí. Reklamace nesprávně zvoleného ANNEXu nebude uznána.



OVERVIEW

The Cisco® RV132W Wireless-N ADSL2+ VPN Router is easy to use, set up, and deploy. This flexible router offers great performance and is suited for small or home offices (SOHO) and smaller deployments.

The RV132W can be used to connect to an ADSL2+ interface or a regular Ethernet WAN interface. The model supports the free Cisco Small Business FindIT Network Discovery Utility, which allows for automatic discovery and one-click software downloads.
The RV132W comes with a limited lifetime warranty and award-winning support. Table 1 shows the product’s specifications.

*VPN security
*Built-in three-port Fast Ethernet switch
*Asymetrical Digital Subscriber Line 2 plus (ADSL2+) connectivity
*Fast Ethernet WAN
*USB 3G/ 4G/ LTE
*Limited lifetime warranty
*Industry-leading support
*Internal antennas
*Sleek new design

TECHNICAL SPECS

Standards
*IEEE 802.11n, 802.11g, 802.11b, 802.3, 802.3u, 802.1D, 802.1p, 802.1w (Rapid Spanning Tree), 802.1X (security authentication), 802.1Q (VLAN), 802.11i (Wi-Fi Protected Access [WPA2] security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460), Routing Information Protocol (RIP) v1 (RFC 1058), RIP v2 (RFC 1723)
Ports
*LAN, WAN, USB, console
Switch
*Power button (on, off)
Buttons
*Reset, Wi-Fi on, off
Cabling type
*Category 5e or better
LEDs
*Power, DSL or WAN, Internet, LAN (ports 1-3), wireless, VPN, USB
Operating system
*Linux
Network
Network protocols
*Dynamic Host Configuration Protocol (DHCP) server

*Point-to-Point Protocol over Ethernet (PPPoE)

*Point-to-Point Tunneling Protocol (PPTP)

*DNS proxy

*DHCP relay agent

*Internet Group Management Protocol (IGMP) proxy and multicast forwarding

*Rapid Spanning Tree Protocol (RSTP)

*Dynamic Domain Name System (DynDNS, NOIP)

*Network Address Translation (NAT), Port Address Translation (PAT)

*One-to-one NAT

*Port management

*Port mirroring

*Software configurable DMZ to any LAN IP address

*Session Initiation Protocol (SIP) Application Layer Gateways (ALG)
LAN
*3 10/ 100-Mbps LAN ports with a managed switch
WAN
*1 10/ 100-Mbps FE WAN port
WAN
*1 ADSL2+
WLAN
*Built-in high-speed 802.11n wireless access point
Routing protocols
*Static routing

*Dynamic routing

*RIP v1 and v2

*Inter-VLAN routing
Network Address Translation (NAT)
*Port Address Translation (PAT), Network Address Port Translation (NAPT) protocol
VLAN support
*Port-based and 802.1Q tag-based VLANs
Number of VLANs
*6 active VLANs (2-4094 range)
IPv6
*Dual-stack IPv4 and IPv6

*6rd

*Stateless address auto-configuration

*DHCPv6 server for IPv6 Clients on a LAN

*DHCPv6 client for WAN connectivity

*Internet Control Message Protocol (ICMP) v6

*Static IPv6 routing

*Dynamic IPv6 routing with RIPng
Network edge (DMZ)
*Software-configurable to any LAN IP address
Layer 2
*802.1Q-based VLANs, 6 active VLANs
Security
Firewall
*Stateful packet inspection (SPI) firewall, port forwarding and triggering, denial-of-service (DoS) prevention, software-based DMZ

*DoS attacks prevented:

*SYN Flood

*Echo Storm

*ICMP Flood

*UDP Flood

*TCP Flood

*Block Java, cookies, active-X, HTTP proxy
Access control
*IP access control lists; MAC-based wireless access control
Content filtering
*Static URL blocking or keyword blocking
Secure management
*HTTPS, username and password complexity
Wi-Fi Protected Setup (WPS)
*WPS
User privileges
*2 levels of access: admin and guest
Quality of Service (QoS)
QoS
*802.1p port-based priority on LAN ports, application-based priority on WAN ports

*4 queues

*Differentiated Services Code Point (DSCP) support

*Class of Service (CoS)

*Bandwidth management for service prioritization
Performance
NAT throughput
*75 Mbps (Ethernet WAN)
Concurrent sessions
*2000
IPsec VPN throughput (3DES, AES)
*3 Mbps
Configuration
Web user interface
*Simple, browser-based configuration (HTTP, HTTPS)
Command-line interface (CLI)
*Command line using SSH
Management
Web user interface
*Simple, browser-based configuration (HTTP, HTTPS)
CLI
*Command line using SSH
Management protocols
*Web browser, Bonjour, Universal Plug and Play (UPnP)
Event logging
*Local, syslog, email alerts
Network diagnostics
*Ping, Traceroute, DNS lookup, and port mirror
Upgradability
*Firmware-upgradable through a web browser, imported or exported configuration file
System time
*Supports NTP, daylight savings, manual entry
Languages
*GUI supports English
Wireless
Radio and modulation type
*802.11b: direct sequence spread spectrum (DSSS), 802.11g: orthogonal frequency division multiplexing (OFDM), 802.11n: OFDM
WLAN
*2.4 GHz IEEE 802.11n standard-based access point with 802.11b/ g compatibility
Operating channels
*11 North America, 13 most of Europe, auto-channels selection
Wireless isolation
*Wireless isolation between clients
Internal antennas
*2
Antenna gain in dBi
*3 dBi
Transmit power
*802.11b: 17 dBm +/ - 2.5 dBm; 802.11g: 15 dBm +/ - 2.5 dBm; 802.11n: 15 dBm +/ - 2.5 dBm
Receiver sensitivity
*-85 dBm at 11 Mbps, -73 dBm at 54 Mbps, -68 dBm at mcs15, HT20, -65 dBm at mcs15, HT40
Radio frequency
*Single-band, works on 2.4 GHz
Active WLAN clients
*Supports up to 50 concurrent clients
Multiple SSIDs
*Supports multiple Service Set Identifiers (SSIDs), up to 4 separate virtual networks
Wireless VLAN map
*Supports SSID to VLAN mapping with wireless client isolation
WLAN security
*Wired Equivalent Privacy (WEP), WPA, WPA2-PSK, WPA2-ENT, 802.11i
Wi-Fi Multimedia (WMM)
*WMM, WMM power save (WMM-PS)
Environmental
Power
*12V 1A
Certifications
*FCC, CE, IC, Wi-Fi
Operating temperature
*0° to 40°C
Storage temperature
*-20° to 70°C
Operating humidity
*10% to 85% non-condensing
